Nice M5BAR Instructions And Warnings For Installation And Use

ENGLISH – 27
PROGRAMMING PARAMETERS
Meaning
Level I
parameters
Level II
parameters
Effect after pressing the encoder (A)
Internal Light output function
Consult “Table 6” for information
on the single parameters
OU4
0
24 V warning light
1
OGI
2
Boom closed
3
Boom open
4
Courtesy light
5
Red trafc light
6
Green trafc light
7
One-way trafc light
8
Alternate one-way trafc light
9
Pedestrian trafc light
Displays the number of
programmed manoeuvres
MnP a b c
"a"= one, "b"= thousands, "c"= millions
(press the encoder (A) to scroll the single values)
Displays the number of
manoeuvres completed
MnE t u v
"t"= one, "u"= thousands, "v"= millions
(press the encoder (A) to scroll the single values)
Data deletion
ErS
1
Deletes Bluebus devices
2
Deletes Levels
3
Deletes function values and restores default values
5
Delete all
Displays the rmware version
Fir n m
"n", "m"= board rmware version, in 3-number sequences
[press the encoder (A) twice]
Example: the rst number “bC0”, the second number “2b”
Displays the hardware version
Hdr p q r
"p", "q", "r"= board hardware version, in 3-number sequences
[press the encoder (A) 3 times]
Example: rst number “626”, second number “-Ar”, third number “00”
Diagnostics
din
Refer to the “Display diagnostics” paragraph
Table 6
ADDENDUM - PARAMETER LEGEND
Parameter Description
Parameters of outputs OU1, OU2, OU3
24 V warning light
Flashing of the lamp (0.5 seconds on, 0.5 seconds off) indicates that a manoeuvre is under way
Output active 24 V DC / max 10 W
12 V warning light
Flashing of the lamp (0.5 seconds on, 0.5 seconds off) indicates that a manoeuvre is under way
Output active 12 V DC / max 21 W
OGI
Indicator off: boom closed
Slow ashing: opening manoeuvre
Fast ashing: closing manoeuvre
Indicator steady lit: boom open
Output active 24 V DC / max 10 W
Boom closed
Indicator lit: boom closed
Indicator off: boom in other positions
Output active 24 V DC / max 10 W
Boom open
Indicator lit: boom open
Indicator off: application in other positions
Output active 24 V DC / max 10 W
Boom light warning light
The lamp ashes (0.5 seconds on, 0.5 seconds off) both when a manoeuvre is under way and when the
boom is stationary
Output active 24 V DC / max 10 W
Maintenance indicator
Indicates counting of the manoeuvres completed
Indicator lit for 2 seconds at the start of opening manoeuvre: number of manoeuvres less than 80%
Indicator ashing during the entire manoeuvre: number of manoeuvres between 80% and 100%
Indicator always ashing: number of manoeuvres over 100%
Courtesy light
Light lit for the entire duration of the manoeuvre; after the manoeuvre, it remains lit for a duration
corresponding to the courtesy light time
Red trafc light
Slow ashing: closing manoeuvre
Steady light: boom closed
Light off: boom in other positions
Output active 24 V DC / max 10 W
Pedestrian trafc light
Boom closed: green light inside, red light outside
Boom open: red light inside, green light outside
Boom in other positions: red light inside and outside
