Nice Mercury 310

Mercury 310 Automated Gate System
Installation and Programming Manual
2929
Linear Actuator
Wiring Instructions
Apollo 816 Linear Actuator
TITAN 912L Linear Actuator
IMPORTANT NOTICE!
This section only provides instructions for wiring the Apollo 816 and TITAN 912 actuators
to the Mercury 310 controller, but NOT the mechanical installation of the actuators to the
gate.
For mechanical installation instructions, refer to separate linear actuator installation
manuals, which can be accessed through the links below:
’ Apollo 816 Linear Actuator Installation Instructions (P/N MX4684): https://support.
hysecurity.com/hc/en-us/articles/360043678033-Apollo-816-Linear-Actuator-
Installation-Reference-Manual
’ TITAN 912L Linear Actuator Installation Instructions (P/N MX4685): https://support.
hysecurity.com/hc/en-us/articles/360043164394-TITAN-912L-Actuator-Installation-
Reference-Manual
Linear Actuators
