F600 Step By Step Guide 36
00.037 0.000
00.039 0.000
00.040
Wake detect
feedback
threshold
29.049 0.00 to 327.37 1.00
00.041
Wake detect
delay
29.051 0.0 to 3000.0 875
00.042
Sleep detect
speed
threshold
29.052 0.0 to 6553.5 s 5.0 s
00.043
Sleep detect
delay
29.052 0.0 to 6553.5 s 5.0 s
00.044
Number of
auto-reset
attempts
10.034
None (0), 1 (1), 2 (2), 3 (3), 4 (4), 5 (5),
Infinite (6)
5 (5)
00.045
Auto-reset
delay
10.035 1.0 to 600.0 s 10.0 s
00.046 Pipe fill mode 29.075
Disabled (0), Feedback Level (1), Flow
Switch (2)
Disabled (0)
00.047
Pipe fill
reference
1.024
VM_SPEED_FREQ_REF[MIN] to
VM_SPEED_FREQ_REF[MAX]
Std: 25 Hz
US: 30 Hz
Std: 750 rpm
US: 900 rpm
00.048
Pipe fill
maximum time
29.077 0.0 to 6553.5 s 0.0 s
00.049
Pipe fill
threshold
29.076 0.00 to 327.67 UU 0.00 UU
00.050
Dry well low
load detection
threshold
percent
29.057 0.00% to 100% 1.00 %
00.051
Dry well low
load detection
delay
29.058 0.0 to 6553.5 s 0.0 s
00.052
Dry well low
load mode
29.059
Disabled (0), Alarm Only (1), Trip (2),
Lower PID Output (3)
Disabled (0)
00.053
Dry well low
load PID
output
reduction
29.060 0.00% to 100% 50.00%
00.054
Dry well low
load restart
delay
29.061 0.0 to 6553.5 s 5.0 s
00.055
No flow
detection
threshold
29.069 0.0 to 3000.0 0.0 Hz 0.0 rpm
00.056
No flow
detection band
29.070 0.0 to 3000.0 150.0
00.057
No flow
detection
delay
29.071 0.0 to 6553.5 s 5.0 s
00.058
No flow
setpoint
settling delay
29.072 0.0 to 6553.5 s 1.0 s
Parameter Range Default
Description OL RFC-A RFC-S OL RFC-A RFC-S
