Nikon D5300 Reference Manual

181C The Shooting Menu: Shooting Options
❚❚ Auto ISO Sensitivity control
If Off is chosen for Auto ISO sensitivity control in P, S, A, and M modes, ISO sensitivity
will remain fixed at the value selected by the user (0 67).
When On is chosen, ISO
sensitivity will automatically be adjusted if optimal exposure can not be achieved at
the value selected by the user.
The maximum value for auto ISO sensitivity can be
selected using the Maximum sensitivity option in the Auto ISO sensitivity control
menu (choose lower values to prevent noise (randomly-spaced bright pixels, fog, or
lines, but note that if the ISO sensitivity selected by the user is higher than that
chosen for Maximum sensitivity, the value selected by the user will be used instead;
the minimum value for auto ISO sensitivity is automatically set to ISO 100)).
In modes
P and A, sensitivity will only be adjusted if underexposure would result at the shutter
speed selected for Minimum shutter speed (
1
/2000–1 s, or Auto; in modes S and M,
sensitivity will be adjusted for optimal exposure at the shutter speed selected by the
user).
If Auto (available only with CPU lenses) is selected, the camera will choose the
minimum shutter speed based on the focal length of the lens (auto shutter-speed
selection can be fine-tuned by highlighting Auto and pressing 2).
Slower shutter
speeds will be used only if optimum exposure can not be achieved at the ISO
sensitivity value selected for Maximum sensitivity.
When On is selected, the viewfinder shows ISO-AUTO and the
information display ISO-A.
These indicators flash when
sensitivity is altered from the value selected by the user.
A Maximum Sensitivity/Minimum Shutter Speed
When auto ISO sensitivity control is enabled, the ISO sensitivity
and shutter speed graphics in the information display show the
maximum sensitivity and minimum shutter speed.
A Auto ISO Sensitivity Control
Noise (randomly-spaced bright pixels, fog, or lines) is more likely at higher sensitivities. Use
the High ISO NR option in the shooting menu to reduce noise (0 180). Note that ISO
sensitivity may be raised automatically when auto ISO sensitivity control is used in
combination with slow sync flash modes (available with the built-in flash and the optional
flash units listed on page 232), possibly preventing the camera from selecting slow shutter
speeds. Auto ISO sensitivity control is available only in i-TTL flash control mode (0 192, 233);
in other modes, the value selected for ISO sensitivity will be used for pictures taken with the
built-in flash or optional flash units.
Mi
n
i
mum s
h
utter spee
d
Maximum sensitivit
y

Nikon D5300 Specifications

General

Megapixel	24.2 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Sensor format	Advanced Photo System type-C (APS-C)
Image stabilizer	No
Total megapixels	24.78 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Supported aspect ratios	3:2
Maximum image resolution	6000 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	6000 x 4000, \\r 4496 x 3000, \\r 2992 x 2000
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Continuous Auto Focus, Contrast Detection Auto Focus, Multi Point Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Auto Focus (AF) points selection	Auto, Manual
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash sync-speed	1/200 s
Shoe mounting point type	Hot shoe
Flash exposure correction	-3EV - +1EV (1/3 EV step)
Power source type	Battery
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3.2 \
Display resolution	720 x 480 pixels
Display resolution (numeric)	1036800 pixels
Magnification	0.82 x
Viewfinder type	Optical
USB version	2.0
HDMI connector type	Mini
Product color	Silver
Scene modes	Portrait, Landscape (scenery)
Photo effects	Black&White, Neutral, Vivid
White balance	Auto, Cloudy, Flash, Fluorescent, Incandescent, Manual, Shade, Sunny
Playback modes	Rotation, Slideshow, Zoom
Shooting modes	Aperture priority, Auto, Lens priority, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show
Image processor	EXPEED 4
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3, RAW
Diopter adjustment (D-D)	-1.7 - 1
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL14a
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Cables included	USB
Bundled software	ViewNX 2
Wi-Fi standards	802.11b, 802.11g

Weight and Dimensions

Depth	76 mm
Width	125 mm
Height	98 mm
Weight	480 g
Weight (including battery)	530 g
