Nikon D5300 Reference Manual

256 Technical Notes
Error Messages
This section lists the indicators and error messages that appear in the viewfinder and
monitor.
A Warning Icons
A flashing d in the monitor or s in the viewfinder indicates that a warning or error message
can be displayed in the monitor by pressing the W (Q) button.
Indicator
Solution 0Monitor Viewfinder
Lock lens aperture ring at
minimum aperture (largest
f/-number).
B
(flashes)
Set lens aperture ring to minimum aperture
(highest f-number).
227
Lens not attached
F/s
(flashes)
• Attach non-IX NIKKOR lens. 226
• If non-CPU lens is attached, select mode M.87
Shutter release disabled.
Recharge battery.
d/s
(flashes)
Turn camera off and recharge or replace
battery.
2, 11
This battery cannot be used.
Choose battery designated
for use in this camera.
d
(flashes)
Use Nikon-approved battery. 236
Initialization error. Turn
camera off and then on
again.
d/k
(flashes)
Turn camera off, remove and replace battery,
and then turn camera on again.
2, 11
Battery level is low.
Complete operation and turn
camera off immediately.
—
End cleaning and turn camera off and
recharge or replace battery.
244
Clock not set — Set camera clock.
14,
201
No SD card inserted
S/s
(flashes)
Turn camera off and confirm that card is
correctly inserted.
12
Memory card is locked.
Slide lock to “write” position.
(
(flashes)
Memory card is locked (write protected). Slide
card write-protect switch to “write” position.
12
This memory card cannot be
used. Card may be damaged.
Insert another card.
(/k
(flashes)
• Use approved card. 238
• Format card. If problem persists, card may
be damaged. Contact Nikon-authorized
service representative.
196
• Error creating new folder. Delete files or
insert new memory card.
12,
146
• Insert new memory card. 12
• Eye-Fi card is still emitting wireless signal
after Disable has been selected for Eye-Fi
upload. To terminate wireless transmission,
turn the camera off and remove the card.
204
Not available if Eye-Fi card is
locked.
(/k
(flashes)
Eye-Fi card is locked (write protected). Slide
card write-protect switch to “write” position.
12

Nikon D5300 Specifications

General

Megapixel	24.2 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Sensor format	Advanced Photo System type-C (APS-C)
Image stabilizer	No
Total megapixels	24.78 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Supported aspect ratios	3:2
Maximum image resolution	6000 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	6000 x 4000, \\r 4496 x 3000, \\r 2992 x 2000
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Continuous Auto Focus, Contrast Detection Auto Focus, Multi Point Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Auto Focus (AF) points selection	Auto, Manual
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash sync-speed	1/200 s
Shoe mounting point type	Hot shoe
Flash exposure correction	-3EV - +1EV (1/3 EV step)
Power source type	Battery
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3.2 \
Display resolution	720 x 480 pixels
Display resolution (numeric)	1036800 pixels
Magnification	0.82 x
Viewfinder type	Optical
USB version	2.0
HDMI connector type	Mini
Product color	Silver
Scene modes	Portrait, Landscape (scenery)
Photo effects	Black&White, Neutral, Vivid
White balance	Auto, Cloudy, Flash, Fluorescent, Incandescent, Manual, Shade, Sunny
Playback modes	Rotation, Slideshow, Zoom
Shooting modes	Aperture priority, Auto, Lens priority, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show
Image processor	EXPEED 4
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3, RAW
Diopter adjustment (D-D)	-1.7 - 1
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL14a
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Cables included	USB
Bundled software	ViewNX 2
Wi-Fi standards	802.11b, 802.11g

Weight and Dimensions

Depth	76 mm
Width	125 mm
Height	98 mm
Weight	480 g
Weight (including battery)	530 g
