Nikon D5300 Reference Manual

253Technical Notes
Shooting (P, S, A, M)
Playback
Sound is not recorded with movies: Microphone off is selected for Movie settings > Microphone
(0 128).
Flicker or banding appears during live view or movie recording: Choose an option for Flicker reduction
that matches the frequency of the local AC power supply (0 200).
Menu item can not be selected: Some options are not available in all modes.
Shutter-release disabled:
• Non-CPU lens is attached: rotate camera mode dial to M (0 228).
• Mode dial rotated to S after shutter speed of “Bulb” or “Time” selected in mode M: choose
new shutter speed (0 85).
• If white-balance bracketing is active, shutter release will be disabled and viewfinder
exposure-count display will flash if there is insufficient space on memory card to record all
images in bracketing sequence. Insert new memory card.
Full range of shutter speeds not available:
• Flash in use (0 66).
• When On is selected for Movie settings > Manual movie settings in the shooting menu,
the range of available shutter speed varies with the frame rate (0 129).
Can not select desired aperture: Range of available apertures varies with lens used.
Colors are unnatural:
• Adjust white balance to match light source (0 101).
• Adjust Set Picture Control settings (0 111).
Can not measure white balance: Subject is too dark or too bright (0 106).
Image can not be selected as source for preset white balance : Image was not created with D5300 ( 0 107).
Effects of Picture Control differ from image to image: A (auto) is selected for sharpening, contrast, or
saturation. For consistent results over a series of photos, choose another setting (0 113).
Metering can not be changed: Autoexposure lock is in effect (0 91).
Exposure compensation can not be used: Choose mode P, S, or A (0 82, 92).
Noise (reddish areas or other artifacts) appears in long time-exposures: Turn long-exposure noise
reduction on (0 180).
NEF (RAW) image is not played back: Photo was taken at image quality of NEF (RAW)+JPEG (0 60).
Some pictures are not displayed during playback: Select All for Playback folder.
Note that Current is
automatically selected after photograph is taken (0 175).
“Tall” (portrait) orientation photos are displayed in “wide” (landscape) orientation:
• Select On for Rotate tall (0 176).
• Photo was taken with Off selected for Auto image rotation (0 202).
• Photo is displayed in image review (0 176).
• Camera was pointed up or down when photo was taken (0 202).

Nikon D5300 Specifications

General

Megapixel	24.2 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Sensor format	Advanced Photo System type-C (APS-C)
Image stabilizer	No
Total megapixels	24.78 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Supported aspect ratios	3:2
Maximum image resolution	6000 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	6000 x 4000, \\r 4496 x 3000, \\r 2992 x 2000
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Continuous Auto Focus, Contrast Detection Auto Focus, Multi Point Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Auto Focus (AF) points selection	Auto, Manual
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash sync-speed	1/200 s
Shoe mounting point type	Hot shoe
Flash exposure correction	-3EV - +1EV (1/3 EV step)
Power source type	Battery
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3.2 \
Display resolution	720 x 480 pixels
Display resolution (numeric)	1036800 pixels
Magnification	0.82 x
Viewfinder type	Optical
USB version	2.0
HDMI connector type	Mini
Product color	Silver
Scene modes	Portrait, Landscape (scenery)
Photo effects	Black&White, Neutral, Vivid
White balance	Auto, Cloudy, Flash, Fluorescent, Incandescent, Manual, Shade, Sunny
Playback modes	Rotation, Slideshow, Zoom
Shooting modes	Aperture priority, Auto, Lens priority, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show
Image processor	EXPEED 4
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3, RAW
Diopter adjustment (D-D)	-1.7 - 1
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL14a
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Cables included	USB
Bundled software	ViewNX 2
Wi-Fi standards	802.11b, 802.11g

Weight and Dimensions

Depth	76 mm
Width	125 mm
Height	98 mm
Weight	480 g
Weight (including battery)	530 g
