Nikon D5300 Reference Manual

235Technical Notes
D Notes on Optional Flash Units
Refer to the Speedlight manual for detailed instructions. If the flash unit supports CLS, refer
to the section on CLS-compatible digital SLR cameras. The D5300 is not included in the
“digital SLR” category in the SB-80DX, SB-28DX, and SB-50DX manuals.
If an optional flash unit is attached in shooting modes other than j, %, 3, and ) the flash
will fire with every shot, even in modes in which the built-in flash can not be used.
i-TTL flash control can be used at ISO sensitivities between 100 and 12800. At values over
12800, the desired results may not be achieved at some ranges or aperture settings. If the
flash-ready indicator flashes for about three seconds after a photograph is taken, the flash
has fired at full power and the photograph may be underexposed (CLS-compatible flash
units only; for information on the exposure and flash charge indicators on other units, see
the manual provided with the flash).
When an SC-series 17, 28, or 29 sync cable is used for off-camera flash photography, correct
exposure may not be achieved in i-TTL mode. We recommend that you choose spot
metering to select standard i-TTL flash control. Take a test shot and view the results in the
monitor.
In i-TTL, use the flash panel or bounce adapter provided with the flash unit. Do not use other
panels such as diffusion panels, as this may produce incorrect exposure.
If the controls on the optional SB-910, SB-900, SB-800, SB-700 or SB-600 flash unit or SU-800
wireless Speedlight commander are used to set flash compensation, Y will appear in the
information display.
The SB-910, SB-900, SB-800, SB-700, SB-600, and SB-400 provide red-eye reduction, while the
SB-910, SB-900, SB-800, SB-700, SB-600, and SU-800 provide AF-assist illumination with the
following restrictions:
• SB-910 and SB-900: AF-assist
illumination is available with 17–
135 mm AF lenses, however,
autofocus is available only with the
focus points shown at right.
• SB-800, SB-600, and SU-800: AF-assist
illumination is available with 24–
105 mm AF lenses, however,
autofocus is available only with the
focus points shown at right.
• SB-700: AF-assist illumination is
available with 24–135 mm AF
lenses, however, autofocus is
available only with the focus points
shown at right.
17–19 mm 20–105 mm 106–135 mm
24–34 mm 35–49 mm 50–105 mm
24–135 mm

Nikon D5300 Specifications

General

Megapixel	24.2 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Sensor format	Advanced Photo System type-C (APS-C)
Image stabilizer	No
Total megapixels	24.78 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Supported aspect ratios	3:2
Maximum image resolution	6000 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	6000 x 4000, \\r 4496 x 3000, \\r 2992 x 2000
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Continuous Auto Focus, Contrast Detection Auto Focus, Multi Point Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Auto Focus (AF) points selection	Auto, Manual
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash sync-speed	1/200 s
Shoe mounting point type	Hot shoe
Flash exposure correction	-3EV - +1EV (1/3 EV step)
Power source type	Battery
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3.2 \
Display resolution	720 x 480 pixels
Display resolution (numeric)	1036800 pixels
Magnification	0.82 x
Viewfinder type	Optical
USB version	2.0
HDMI connector type	Mini
Product color	Silver
Scene modes	Portrait, Landscape (scenery)
Photo effects	Black&White, Neutral, Vivid
White balance	Auto, Cloudy, Flash, Fluorescent, Incandescent, Manual, Shade, Sunny
Playback modes	Rotation, Slideshow, Zoom
Shooting modes	Aperture priority, Auto, Lens priority, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show
Image processor	EXPEED 4
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3, RAW
Diopter adjustment (D-D)	-1.7 - 1
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL14a
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Cables included	USB
Bundled software	ViewNX 2
Wi-Fi standards	802.11b, 802.11g

Weight and Dimensions

Depth	76 mm
Width	125 mm
Height	98 mm
Weight	480 g
Weight (including battery)	530 g
