Nikon D5300 Reference Manual

237Technical Notes
* A wireless remote controller can not be attached at the same time as an ME-1 stereo
microphone. Attempting to forcibly attach accessories can damage the camera or
accessory.
Body cap
Body Cap BF-1B/Body Cap BF-1A: The body cap keeps the mirror, viewfinder screen,
and image sensor free of dust when a lens is not in place.
Remote
controls/
wireless
remote
controller
• Wireless Remote Control ML-L3 (0 70): The ML-L3 uses a 3 V CR2025 battery.
Pressing the battery-chamber latch to the right (q), insert a fingernail into the
gap and open the battery chamber (w). Ensure that the battery is inserted in
the correct orientation (r).
• Wireless Remote Controller WR-R10
*
/WR-T10: When a WR-R10 wireless remote
controller is attached, the camera can be controlled wirelessly using a WR-T10
wireless remote controller (0 71, 203). The WR-T10 uses a 3 V CR2032 battery.
Insert a fingernail into the gap behind the battery-chamber latch and open the
battery chamber (q).
Ensure that the battery is inserted in the correct
orientation (e).
• Wireless Remote Controller WR-1 (0 71, 203): WR-1 units are used in groups of two
or more, with one functioning as a transmitter and the remaining units acting
as receivers. The receivers are attached to the accessory terminals of one or
more cameras, allowing the transmitter to be used to release the camera
shutters.
Microphones Stereo Microphone ME-1 (0 129)
*
Accessory
terminal
accessories
The D5300 is equipped with an accessory terminal for
WR-1 and WR-R10 wireless remote controllers (0 71), MC-DC2
remote cords (0 88), and GP-1/GP-1A GPS units (0 81),
which connect with the 4 mark on the connector
aligned with the 2 next to the accessory terminal
(close the connector cover when the terminal is not in
use).
USB and A/V
connector
accessories
• UC-E17 and UC-E6 USB cables (0 153, 156): The supplied UC-E17 cable is not
available for separate purchase; purchase UC-E6 cables instead.
• EG-CP16 audio/video cables
A Optional Accessories
Availability may vary with country or region. See our website or brochures for the latest
information.

Nikon D5300 Specifications

General

Megapixel	24.2 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Sensor format	Advanced Photo System type-C (APS-C)
Image stabilizer	No
Total megapixels	24.78 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Supported aspect ratios	3:2
Maximum image resolution	6000 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	6000 x 4000, \\r 4496 x 3000, \\r 2992 x 2000
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Continuous Auto Focus, Contrast Detection Auto Focus, Multi Point Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Auto Focus (AF) points selection	Auto, Manual
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash sync-speed	1/200 s
Shoe mounting point type	Hot shoe
Flash exposure correction	-3EV - +1EV (1/3 EV step)
Power source type	Battery
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3.2 \
Display resolution	720 x 480 pixels
Display resolution (numeric)	1036800 pixels
Magnification	0.82 x
Viewfinder type	Optical
USB version	2.0
HDMI connector type	Mini
Product color	Silver
Scene modes	Portrait, Landscape (scenery)
Photo effects	Black&White, Neutral, Vivid
White balance	Auto, Cloudy, Flash, Fluorescent, Incandescent, Manual, Shade, Sunny
Playback modes	Rotation, Slideshow, Zoom
Shooting modes	Aperture priority, Auto, Lens priority, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show
Image processor	EXPEED 4
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3, RAW
Diopter adjustment (D-D)	-1.7 - 1
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL14a
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Cables included	USB
Bundled software	ViewNX 2
Wi-Fi standards	802.11b, 802.11g

Weight and Dimensions

Depth	76 mm
Width	125 mm
Height	98 mm
Weight	480 g
Weight (including battery)	530 g
