Nikon D5300 Reference Manual

261Technical Notes
ISO sensitivity
(Recommended
Exposure Index)
ISO 100 – 12800 in steps of
1
/3 EV. Can also be set to approx. 0.3, 0.7, or
1 EV (ISO 25600 equivalent) above ISO 12800; auto ISO sensitivity control
available
Active D-Lighting Y Auto, Z Extra high, P High, Q Normal, R Low, ! Off
Focus
Autofocus Nikon Multi-CAM 4800DX autofocus sensor module with TTL phase
detection, 39 focus points (including 9 cross-type sensor), and AF-assist
illuminator (range approx. 0.5–3 m/1 ft 8 in.–9 ft 10 in.)
Detection range –1 – +19 EV (ISO 100, 20 °C/68 °F)
Lens servo • Autofocus (AF): Single-servo AF (AF-S); continuous-servo AF (AF-C); auto
AF-S/AF-C selection (AF-A); predictive focus tracking activated
automatically according to subject status
• Manual focus (MF): Electronic rangefinder can be used
Focus point Can be selected from 39 or 11 focus points
AF-area mode Single-point AF, 9-, 21-, or 39- point dynamic-area AF, 3D-tracking, auto-
area AF
Focus lock Focus can be locked by pressing shutter-release button halfway (single-
servo AF) or by pressing A (L) button
Flash
Built-in flash i, k, p, n, o, s, w, g, ' : Auto flash with auto pop-up
P, S, A, M, 0: Manual pop-up with button release
Guide Number Approx. 12/39, 13/43 with manual flash (m/ft, ISO 100, 20 °C/68 °F)
Flash control TTL: i-TTL flash control using 2016-pixel RGB sensor is available with
built-in flash and SB-910, SB-900, SB-800, SB-700, SB-600, SB-400, or
SB-300; i-TTL balanced fill-flash for digital SLR is used with matrix and
center-weighted metering, standard i-TTL flash for digital SLR with spot
metering
Flash mode Auto, auto with red-eye reduction, auto slow sync, auto slow sync with
red-eye reduction, fill-flash, red-eye reduction, slow sync, slow sync with
red-eye reduction, rear-curtain with slow sync, rear-curtain sync, off
Flash compensation –3 – +1 EV in increments of
1
/3 or
1
/2 EV
Flash-ready indicator Lights when built-in flash or optional flash unit is fully charged; flashes
after flash is fired at full output
Accessory shoe ISO 518 hot-shoe with sync and data contacts and safety lock
Nikon Creative Lighting
System (CLS)
Advanced Wireless Lighting supported with SB-910, SB-900, SB-800, or
SB-700 as a master flash or SU-800 as commander; Flash Color
Information Communication supported with all CLS-compatible flash
units
Sync terminal AS-15 sync terminal adapter (available separately)
White balance
White balance Auto, incandescent, fluorescent (7 types), direct sunlight, flash, cloudy,
shade, preset manual, all except preset manual with fine-tuning.
Exposure

Nikon D5300 Specifications

General

Megapixel	24.2 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Sensor format	Advanced Photo System type-C (APS-C)
Image stabilizer	No
Total megapixels	24.78 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Supported aspect ratios	3:2
Maximum image resolution	6000 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	6000 x 4000, \\r 4496 x 3000, \\r 2992 x 2000
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Continuous Auto Focus, Contrast Detection Auto Focus, Multi Point Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Auto Focus (AF) points selection	Auto, Manual
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash sync-speed	1/200 s
Shoe mounting point type	Hot shoe
Flash exposure correction	-3EV - +1EV (1/3 EV step)
Power source type	Battery
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3.2 \
Display resolution	720 x 480 pixels
Display resolution (numeric)	1036800 pixels
Magnification	0.82 x
Viewfinder type	Optical
USB version	2.0
HDMI connector type	Mini
Product color	Silver
Scene modes	Portrait, Landscape (scenery)
Photo effects	Black&White, Neutral, Vivid
White balance	Auto, Cloudy, Flash, Fluorescent, Incandescent, Manual, Shade, Sunny
Playback modes	Rotation, Slideshow, Zoom
Shooting modes	Aperture priority, Auto, Lens priority, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show
Image processor	EXPEED 4
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3, RAW
Diopter adjustment (D-D)	-1.7 - 1
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL14a
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Cables included	USB
Bundled software	ViewNX 2
Wi-Fi standards	802.11b, 802.11g

Weight and Dimensions

Depth	76 mm
Width	125 mm
Height	98 mm
Weight	480 g
Weight (including battery)	530 g
