Page #400 background imageLoading...
Page #400 background image
376 Technical Notes
❚❚ AF-S DX NIKKOR 55–200mm f/4–5.6G ED VR II Lens
Nikon reserves the right to change the specifications of the hardware and software described in
this manual at any time and without prior notice.
Nikon will not be held liable for damages that
may result from any mistakes that this manual may contain.
Type Type G AF-S DX lens with built-in CPU and F
mount
Focal length 55–200 mm
Maximum aperture f/4–5.6
Lens construction 13 elements in 9 groups (including 1 ED lens
element)
Angle of view 28° 50 ´ – 8°
Focal length scale Graduated in millimeters (55, 70, 85, 105, 135,
200)
Distance information Output to camera
Zoom Manual zoom using independent zoom ring
Focusing Nikon Internal Focusing (IF) System with
autofocus controlled by Silent Wave Motor and
separate focus ring for manual focus
Vibration reduction Lens shift using voice coil motors (VCMs)
Minimum focus distance 1.1 m (3.7 ft) from focal plane (0 89) at all zoom
positions
Diaphragm blades 7 (rounded diaphragm opening)
Diaphragm Fully automatic
Aperture range 55 mm focal length: f/4–22
200 mm focal length: f/5.6–32
Metering Full aperture
Filter-attachment size 52 mm (P = 0.75 mm)
Dimensions Approx. 70.5 mm maximum diameter × 83 mm
(distance from camera lens mount flange when
lens is retracted)
Weight Approx. 300 g (10.6 oz)

Table of Contents

Other manuals for Nikon D5500

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Nikon D5500 and is the answer not in the manual?

Nikon D5500 Specifications

General IconGeneral
Megapixel24.2 MP
Camera typeSLR Camera Body
Sensor typeCMOS
Image stabilizerNo
Total megapixels24.78 MP
Image sensor size- \
Image formats supportedJPG, RAW
Maximum image resolution6000 x 4000 pixels
Image sensor size (W x H)23.5 x 15.6 mm
Still image resolution(s)(L) 6000 x 4000, (M) 4496 x 3000, (S) 2992 x 2000
Optical zoom- x
Focal length range- mm
Lens mount interfaceNikon F
Minimum aperture number-
FocusTTL
Focus adjustmentAuto/Manual
Auto Focus (AF) lockYes
Auto Focus (AF) points39
Auto focusing (AF) modesContinuous Auto Focus, Single Auto Focus
Light meteringCentre-weighted, Matrix, Spot
ISO sensitivity100, 25600
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)25600
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction±5EV (1/2; 1/3 EV step)
Camera shutter typeElectronic
Shutter speed settingsB, T
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed30 s
Flash modesAuto, Fill-in, Flash off, Red-eye reduction, Second curtain synchro, Slow synchronization
Flash sync-speed0.005 s
Flash guide number12 m
Shoe mounting point typeHot shoe
Flash exposure correction-3EV - +1EV (1/2; 1/3 EV step)
Power source typeBattery
Video resolutions640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate60 fps
Video formats supportedH.264, MOV, MPEG4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed640x424@30fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps
Audio formats supportedLPCM
Memory slots1
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3.2 \
Display resolution720 x 480 pixels
Display resolution (numeric)1036800 pixels
Magnification0.82 x
USB version2.0
HDMI connector typeMini
Security algorithmsAES, WPA2-PSK, WPS
Data networkNot supported
Wi-Fi standards802.11b, 802.11g
Eye relief17 mm
Scene modesBeach, Candlelight, Children, Close-up (macro), Dawn, Dusk, Food, Night landscape, Night portrait, Party (indoor), Pet, Portrait, Snow, Sports, Sunset, Landscape (scenery)
Photo effectsBlack&White, Neutral, Vivid
White balanceAuto, Cloudy, Flash, Fluorescent, Incandescent, Manual, Shade, Sunny
Camera playbackHighlights, Movie, Single image, Slide show, Thumbnails
Self-timer delay2, 5, 10, 20 s
Languages supportBEN, ARA, BUL, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUS, SER, SWE, TUR, UKR
Camera file systemDCF 2.0, DPOF, Exif 2.3
Diopter adjustment (D-D)-1.7 - 0.5
Battery typeEN-EL14a
Product colorBlack, Red
Operating temperature (T-T)0 - 40 °C
Cables includedAV, USB
Weight and Dimensions IconWeight and Dimensions
Depth70 mm
Width124 mm
Height97 mm
Weight420 g
Weight (including battery)470 g
