5 Menu Key
108 Nikon N Series/K Series Total Station Instruction Manual
8. Press the OK soft key or [ENT], and the
coordinates are calculated allocating the error
by the method set for error distribution and
recorded.
9. Upon completion of recording, the window on
the right is displayed and returns to the Cogo
Input menu window.
Traverse adjustment applies to Closed traverse and Closed-loop traverse.
Closed traverse Closed-loop traverse
Coordinates of measurement point are calculated also from the unknown points
such as P1, P2 and P3 shown in the figure below.
Backsight point
Foresight point
Start point
End point
: Known point
: Unknown point
Backsight point
Foresight point
Start point
End point
