Nikon K 5 - Parts of the Instrument

Nikon N Series/K Series Total Station Instruction Manual 3
Introduction 1
Parts of the Instrument
Figure 1.1 and Figure 1.2 show the main parts of the instrument.
Figure 1.1
Telescope
Telescope
Diopter ring
Vertical tangent
Vertical clamp
Horizontal
screw
tangent screw
focusing ring
eyepiece
Face-1 display /
Carrying handle
Optical sight
(Finder)
Reticle plate cover
CFR label is attached here.
Tribrach clamp knob
Horizontal clamp
FCC label is attached here.
Battery case
mounting button
Keyboard
Nikon N Series/K Series --- Face-1
(Carrying hanndle
doesn’t interfere
with the zenith
measurement.)
