Nikon s4300 - Camera Body Diagram

2
Parts of the Camera and Basic Operations
Parts of the Camera and Basic Operations
Parts of the Camera
The Camera Body
3
2
1
5
8
9
7
4
6
Lens cover closed
1 Shutter-release button......................13, 30
2
Zoom control..................................................29
f: Wide-angle ..........................................29
g: Telephoto ...............................................29
h: Thumbnail playback.....................33
i: Playback zoom ....................................33
3
Power switch/power-on lamp
......................................................... 22, 23, E75
4 Flash ......................................................................55
5
Self-timer lamp...............................................57
AF-assist illuminator...................89, E73
6 Lens
7 Built-in microphone...................82, E58
8 Lens cover .................................................... F2
9 Eyelet for camera strap..............................13
