Introduction to the X-ray system
XT V 160 X-ray System XTM0011-F2 27
The monitor can be rotated by releasing both grub screws at the top of the mount. These
should be re-tightened after adjustment.
Do not use the grub screws to hold the monitor post in a raised
position, adjust height using the locking lever.
The amount of force needed to move the monitor arm and control console arm can be
adjusted by tightening or loosening the resistance grub screws located at each hinge point.
