XT V 160 X-ray System XTM0011-F2 37
There is no recommended time to hold the X-ray source at the maximum kV during
auto-conditioning. The longer it is held there, the more stable the X-ray source will be at
higher kV values.
If auto-conditioning fails repeatedly, then it generally means that the
X-ray source needs cleaning.
5.3 Check the status of the system
The Inspect-X System Status window shows the detailed status of the system and whether
interlocks have been made to allow the manipulator to be moved within the cabinet and
X-rays to be generated. If interlocks are not made, and the doors on the inspection system
are closed correctly, the information in the System Status window may help to identify
possible problems.
The System Status also appears at the top of the Inspect-X window:
To view the status of the system, follow these steps:
1. Click .
The System Status window opens.
2. If the X-ray controller interlock is not made, check that:
• The INTERLOCK key is in the ON position.
• All cabinet doors are closed.
• The X-ray ON Lamp is operating correctly.
• The turbo pump is up to speed (shown in the System Status window).
• The vacuum is below the set point (shown in the System Status window).
• The coolant flow and level is correct.
3. If the manipulator interlock is not made, check that:
• The INTERLOCK key is in the ON position.
• All cabinet doors are closed.
4. Click the Close icon (X) to close the System Status window.
5.4 Inspect a sample
This section provides an overview of the main steps required to inspect a sample and
capture and save an image. It assumes the system is switched on and the source is
conditioned and ready for use.
For more detailed instructions on using Inspect-X to inspect a sample,
refer to the Inspect-X Online Help or User Manuals.
5.4.1 Home the manipulator
