Maintenance
XT V 160 X-ray System XTM0011-F2 77
6.2.6 Fuse list
ID Type Function ID Type Function
F2 8A gG 10x38 230V AC T1 O/P F24 2A T 5x20 230V AC DETECTOR
PSU
F3 10A aM 10x38 75V AC T1 O/P F25 5x20 230V AC SPARE
F4 10A aM 10x38 75V AC T1 0/P F26 3.15A T
5x20
+24V SR
F5 6A DC 10x38 100V DC SUPPLY F27 6.3A T 5x20 +24V SOURCE
F6 5A T 5x20 230V AC PSU1
SUPPLY
F28 4A T 5x20 +48V SOURCE
F7 5A T 5x20 230V AC PSU2
SUPPLY
F29 5A T 5x20 24V DC
INTENSIFIER
OPTION
F8 5A T 5x20 230V AC
BACKING PUMP
F20 1A T 5x20 24V DC PSU5 LASER
POINTER
F9 3.15A 5x20 230V AC
COOLANT PUMP
F21 1A T 5x20 24V DC IRIS & JSB
SUPPLY
F20
3.15A 5x20
230V AC
MONITOR
F22 2A T 5x20 24V DC COOLING
TRAY FANS
F21 3.15 A T 5x20 230V AC
AQUISITION PC
F23 2A T 5x20 24V DC ELECTRICAL
AREA FANS
F22
5A T 5x20
230 VAC
PSU3 SUPPLY
F24 2A T 5x20 24V DC
MANIPULATOR
AUX.
F23 2A T 5x20 230V AC
CABINET LIGHT
F25 2A T 5x20 24V DC CT ARM
F26 500mA T
5x20
24V DC XODIAC
MODULE
6.2.7 Radiation integrity
An annual radiation survey on the system is required.
A radiation survey must be performed if the system is moved from one
location to another or if any work is undertaken on the system which
breaks the integrity of the cabinet lead shielding.
