Show data
I
t is possible to read off current data for the unit.
Show data
↳
Operating state Description: Shows the operating setting in which the unit is
running.
↳
T1 Outdoor air Description: Shows the outdoor temperature before reaching the
pre-heating element.
↳
T2 Supply air Description: Shows the supply air temperature. If an after-heating
element has been installed, T7 will be shown instead.
↳
T5 Condenser Description: Shows the condenser temperature.
↳
T6 Evaporator Description: Shows the evaporator temperature.
↳
T7 Supply air Description: Shows the supply air temperature if an after-heating
element has been installed. Otherwise T2 will be
shown.
↳
T10 Extract air/Room Description: Shows the current room temperature as measured in
the extract air.
↳
Air humidity Description: Shows the current air humidity in the dwelling.
↳
CO2 Description: Shows the current CO
2
level in the dwelling (only if
installed).
↳
Supply air fan Description: Shows the level at which the supply air fan is
operating.
↳
Extract air fan Description: Shows the level at which the extract air fan is
operating.
↳
Unit information Description: Press "Unit information" for more information.
↳
Unit type Description: Shows the name of the product the software has been
set to work with.
↳
Software version Description: Shows the installed software version.
↳
Panel software Description: Shows installed software version on the panel.
Date/Time
It is important to set date and time correctly. It makes it easier to localise errors indicated in an error
report. When logging data, it is important to be able to follow the history. The time is shown under
“Date / Time” in the display.
Date / Time
↳
Year Description: Select "Year" in the panel and then select the correct
year.
↳
Month Description: Select "Month" in the panel and then select the correct
month.
↳
Day Description: Select "Day" in the panel and then select the correct
day.
↳
Hour Description: Select "Hour" in the panel and then select the correct
hour.
↳
Minute Description: Select "Minute" in the panel and then select the correct
amount of minutes.
12
