Temp. control
If you wish to control the supply air temperature, an after-heating element must be installed. An after-
heating element allows you to control the supply air temperature, regardless of the outdoor
temperature.
An external electrical or water after-heating element can be installed in the supply air duct.
ATTENTION
When heating is not needed in the dwelling, the supply air temperature may fall below the
minimum temperature.
Temp. control
↳ Min. supply air summer Settings:
Standard setting:
Description:
5 ↔ 16 °C
14 °C
Here you set the minimum supply air temperature that
the unit should provide in the summer. If the outdoor
air temperature is lower than stated, the bypass
damper closes, the system runs with heat recovery.
↳
Min. supply air winter Settings:
Standard setting:
Description:
14 ↔ 22 °C
16 °C
Here you set the minimum supply air temperature that
the unit should provide in the winter. Only effective
with an after-heating element.
↳
Max. supply air summer Settings:
Standard setting:
Description:
16 ↔ 25 °C
22 °C
Here, the supply air temperature is set, the unit as
maximum must be able to blow in with when heat is
needed.
↳
Max. supply air winter Settings:
Standard setting:
Description:
22 ↔ 50 °C
25 °C
Here you can set the maximum supply air temperature
that the unit should provide when heating is required
in the winter (only displayed on the panel if the unit is
fitted with an after-heating element).
↳
Summer change Settings:
Standard setting:
Description:
5 ↔ 30 °C
12 °C
Here you set the minimum outdoor temperature for
the unit to operate in summer mode. If the outdoor air
temperature is lower, the unit will operate in winter
mode.
Language
The unit is factory-set to Danish language. You can change the texts to other languages.
Language
↳ Danish Description: Select the desired language on the panel.
20
