nilan CTS602 HMI Software Instructions

User selection 2
Y
ou can set the user selection program using special settings that override the operating mode in the
main menu. The user selection program is activated via an external signal.
The user selection program is used, for instance, for connecting a cooker hood. Ventilation runs at a
high level during cooker hood operation. The program can also be used for other functions such as to
create imbalance in supply air and extract air ventilation. (User selection 2 will only be displayed if an
expansion PCB has been installed).
When user selection 2 is active, an icon is displayed on the main screen
Service / User selection
↳
Select program Settings:
Standard setting:
Description:
No / Expanded / Supply air / Extract air / Ext. offset /
V
entilate / Cooker hood
No
Select the program you wish to run.
↳
Expanded Description: If you select expanded.
↳
Duration Settings:
Standard setting:
Description:
Off / 15 ↔ 480 minutes
Off
Time runs with 15 minute intervals. Select for how long
the program is to continue after the external signal has
ceased.
↳
Fan speed level Settings:
Standard setting:
Description:
Level 1 / Level 2 / Level 3 / Level 4 / Off
Level 4
Select the desired fan speed level.
↳ Room temperature Settings:
Standard setting:
Description:
5 ↔ 30 °C
23 °C
Set the desired room temperature.
↳ Supply air Description: If you select supply air.
↳
Duration Settings:
Standard setting:
Description:
Off / 15 ↔ 480 minutes
Off
Time runs with 15 minute intervals. Select for how long
the program is to continue after the external signal has
ceased.
↳
Fan speed level Settings:
Standard setting:
Description:
Level 1 / Level 2 / Level 3 / Level 4 / Off
Level 4
Select the desired fan speed level.
↳ Extract air Description: If you select extract air.
↳
Duration Settings:
Standard setting:
Description:
Off / 15 ↔ 480 minutes
Off
Time runs with 15 minute intervals. Select for how long
the program is to continue after the external signal has
ceased.
↳
Fan speed level Settings:
Standard setting:
Description:
Level 1 / Level 2 / Level 3 / Level 4 / Off
Level 4
Select the desired fan speed level.
↳Ventilate Description: If you select ventilate.
↳
Duration Settings:
Standard setting:
Description:
Off / 15 ↔ 480 minutes
Off
Time runs with 15 minute intervals. Select for how long
the program is to continue after the external signal has
ceased.
VPL28 (English)
BY NILAN
23
