ENGLISH USER MANUAL
12 SW4000 - 1464809000
WIRING DIAGRAM
Key
BAT 24 V batteries
BZ1 Reverse gear buzzer
BE Flashing light
C1 Battery connector
CH Battery charger
EB1 Drive system electronic board
EB2 Dashboard electronic board
ES0 Line electromagnetic switch
ES1 Main broom electromagnetic switch
FA Main broom fuse (50 A)
F0 Main fuse (150 A)
F1 Vacuum system fuse (25 A)
F2 Filter shaker fuse (25 A)
F3 Display electronic board (3 A)
F4 Key circuit fuse (10 A)
F5 Dust guard system pump fuse (5 A) (optional)
F6 Hopper pump fuse (25 A)
FR1 Right side broom circuit breaker (15 A)
FR2 Left side broom circuit breaker (15 A) (optional)
HN Horn
K1 Vacuum system relay
K2 Filter shaker relay
K3A Hopper lifting relay
K3B Hopper lowering relay
K4 Machine on relay
K5 Side broom relay
K6 Dust guard system pump relay (optional)
L1, L2 Working lights (optional)
M0 Driving wheel
M1 Vacuum system motor
M2 Filter shaker motor
M3 Hopper pump motor
M4 Main broom motor
M6 Right side broom motor
M7 Left side broom motor (optional)
M8 Dust guard system pump motor (optional)
R1 Drive pedal
S1 Hopper lifting sensor
S2 Main broom lever sensor
S3 Side broom lever sensor
SW0 Emergency push-button
SW1 Ignition key
SW2 Forward/reverse gear switch
SW3 Filter shaker/vacuum system switch
SW4 Hopper enabling switch
SW5 Hopper lifting/lowering switch
SW6 Horn switch
SW7 Driver’s seat safety microswitch
SW8 Dust guard system switch (optional)
SW9 Working light switch (optional)
Colour codes
BK Black
BU Blue
BN Brown
GN Green
GY Grey
OG Orange
PK Pink
RD Red
VT Violet
WH White
YE Yellow
