36 / 76 ♦ BKI16ATEX0018X ♦ htk4014a0600p_03
Function Input Range Description
1.2.0 Display
Select m, cm, mm, inch, ft h optional unit* 1.2.4 Length unit
mm
Unit for display of level and distance.
*When “optional unit” selected, you get to the menu item Fct. 1.2.6:
New unit and can there define user-defined units.
The unit selected here is also valid for the following functions,
if “Level” or “Distance” is selected in Fct. 1.3.1:
Fct. 1.1.1 Tank height,
Fct. 1.1.2 Dead zone,
Fct. 1.1.6 Probe length,
Fct. 1.3.3 Scale I1 min.,
Fct. 1.3.4 Scale I1max.,
Fct. 1.5.1 Detection delay and
Fct. 1.7.2 Input table*
In addition the displayed value will use the selected unit.
Select m³, l, US Gal, ft³, bbl, m³/h, ft³/h, kg,
metric tonnes or tons US
1.2.5 Volume unit
m³
Unit of displayed volume / conversion value.
Conversion means converting a level value
into a “conversion value” (usually volume) in order
e.g. to realize a non-linear function as a factor of the level.
The unit selected here is also valid for the following functions, if “Volume” selected in Fct.
1.3.1:
Fct. 1.3.3 Scale I1 min.
Fct. 1.3.4 Scale I1 max.
Fct. 1.7.2 Input table
• New unit (length)
Appears only when “Optional unit” is selected in Fct. 1.2.4: Length unit.
4 ASCII characters 1.2.5.1 Unit name
Unit
Name of the new unit (max. 4 characters)
Minimum: > 0.0
Maximum: 100 000
1.2.5.2 Unit fact.
1.0
Reference for the conversion factor is the millimetre.
At a conversion factor of 10, the new unit is equivalent to 10 mm.
At a conversion factor of 0.1, the new unit is equivalent to 0.1 mm.
