Function (Fct.) Input Range Description
5.0 HART® VARIABLES
5.1 MANUFACTURER
NIVELCO
Read only menu
5.2 MODEL Read only menu
5.3 FLD DEV REV
1.0
Field device revision.
Read only menu
5.4 SOFTWARE REV
1.0
Software revision.
Read only menu
5.5 HARDWARE REV
1.0
Hardware revision.
Read only menu.
5.6 DEVICE ID Read only menu. The device ID is also the serial number of the device.
5.7 MESSAGE 32 bytes of ASCII characters
5.8 DESCRIPTOR 16 bytes of ASCII characters
5.9 DATE Month Day Year (xx / xx / xx).
5.10 NUM RESP PREAM Number of preamble in the response frame of the device
5.11 TAG Tag name of the MicroTREK 2-wire
5.12 POLL ADDRESS Address of the device.
5.3.1 CHARACTERS AVAILABLE FOR ALPHA-NUMERICAL DATA FUNCTIONS IN PCSTAR2 AND ON THE HART
®
CONSOLE
PCSTAR2 Fct. 12.6.1: Unit name, Fct. 1.4.4: Device number, Fct. 1.4.8: Option
HART® console (HHC) Fct. 5.7 Message, Fct. 5.8 Descriptor, Fct. 5.11 Tag
@ H P X Space ( 0 8
A I Q Y ! ) 1 9
B J R Z “ * 2 :
C K S [ # + 3 ;
D L T \ $ ‘ 4 <
E M U ] % - 5 =
F N V ^ & . 6 >
G O W _ ‘ / 7 ?
