5.6 APPENDIX 1 – SET-UP PARAMETERS OF MICROTREK H-400 SERIES IN MULTICONT CONTROLLER
Remote program 90
Basic setup
Output setup
Application
Service
Applicati on 97
Tresho ld
Service 89
Service code
Application type
Epsilon R
Tres hold 98
Ampl= 00 345 mV
Dist.= 1.25 m
Pulse ampl.= 820mV
Gain= 3
Output setup 92
Current mode
Curren t min.
Curren t max.
Failure current
Error current
Length u nit 120
m
cm
mm
ft
inch
Error delay 95
None
10 sec
20 sec
30 sec
1 min
2 min
5 min
15 min
Current mode 93
Level
Distan ce
Volum e
Ullage volume
Failure current 94
Hold
22 mA
Application type 94
1 Liq. 1 Level
2 Liq. 1 Level
Basic se tup 91
Length unit
Tank height
Dead zone
Close-end blocking
Damping time
Probe length
Parameters in the Service Menu are read-only parameters. Changing of these parameters require the service code of the instrument.
