50 / 76 ♦ BKI16ATEX0018X ♦ htk4014a0600p_03
5.3 PROGRAMMING WITH HART
®
HANDHELD (HHC) COMMUNICATOR
Display and configuration can also be carried out with a HART® communicator...
1 Two-pin jack for loop connectors
2 LCD
3 Function keys (F1 … F4)
Action keys
On/off
UP
Arrow
n/a
LEFT
Arrow
DOWN
Arrow
RIGHT
Arrow
Communicator layout
4
Other functions: LEFT Arrow: Previous menu key
RIGHT Arrow: Select key
Wiring, standard (non-Ex)
Caution: Refer to the HHC manual for wiring instructions when in an explosive atmosphere.
