Displaying readings
Use the UP and DOWN arrows to move to the correct line and then select with the RIGHT Arrow.
Online
1 → <Process Var.>
2 <Config./Test>
3 <Access/Rights>
4 <Watch status>
5 <HART Variables>
HART Communicator
1 Offline
2 → Online
3 Frequency Device
4 Utility
SAVE
1
F1 F2 F3 F4
2
F1 F2 F3 F4
Main menu Online menu
<Process Var.>
1 → <Measurements>
2 <Input/Outputs>
♥
<Measurements>
1 → Lvl 878.00 mm
2 Dist 121.00 mm
SAVE HOME HELP SAVE HOME
3
F1 F2 F3 F4
4
F1 F2 F3 F4
Measurement & input & output functions menu Measurement display function
