52 / 76 ♦ BKI16ATEX0018X ♦ htk4014a0600p_03
Configuration: summary of user functions via HART® Communicator HC 275 (Version 1.00)
Reset default values are in bold type in the “Input Range” column.
Refer to the HART® HC275 Communicator operating instructions for further operating details.
Function (Fct.) Input Range Description
1.0 PROCESS VAR.
1.1.0 MEASUREMENTS
1.1.1 LEVEL Level value
1.1.2 DISTANCE Distance value
1.1.3 VOLUME Volume value if a strapping table is programmed
1.1.4 ULLAGE VOLUME Ullage Volume value if a strapping table is programmed
1.2.0 INPUTS/OUTPUTS
1.2.1 FUNCTION I Function associated to the current output (Primary Variable).
1.2.2 I Current output value (mA)
1.2.3 % Percentage of PV range
