Nobles Marksman 412 - SPECIFICATIONS

OPERATION
Marksmant 412 (01–01)
11
SPECIFICATIONS
Model Marksmant 412
LENGTH 533 mm (21 in) with handle folded
WIDTH 330 mm (13 in)
HEIGHT 749 mm (29.5 in) with handle folded
WEIGHT 27 Kg (60 lb)
SOLUTION TANK CAPACITY 15 L (4 gal)
RECOVERY TANK CAPACITY 15 L (4 gal)
CLEANING PATH WIDTH 273 mm (10.75 in)
MAXIMUM CLEANING RATE 130 m
2
(1,400 sq. ft.) per hour
BRUSH MOTOR 120VDC, 0.1HP, .75A, 90W, 1800 rpm – no load
230VDC, 0 .1HP, .38A, 90W, 1800 rpm – no load
BRUSH SPEED 1038 rpm – no load
SOLUTION PUMP 120VDC, 4.1 bar (60psi), .7 A, 5.3 LPM (1.4 GPM)
230VDC, 4.1 bar (60psi), .35A, 5.3 LPM (1.4 GPM)
VACUUM MOTOR 120VDC, 1.5 HP, 9.1A, 1092W, 2 stage, 103 cfm
230VDC, 1.4 HP, 4.7A, 1046W, 2 stage, 105 cfm
240VDC, 1.5 HP, 5.0A, 1138W, 2 stage, 111 cfm
SEALED WATER LIFT 120V model –2324 mm (91.5 in), 230Vmodel –2514mm (99 in)
TOTAL POWER CONSUMPTION 120 VAC, 10.6 A, 1272 W
230VAC, 5.4A, 1249 W
POWER CORD 7.6 M (25 ft.) 16/3–120V, 3X1.5MM
2
–230V
DECIBEL RATING AT OPERATOR’S EAR,
INDOORS ON CARPET
<72 dB(A)
MACHINE DIMENSIONS
330 mm
(13.0 in)
914 mm
(36.0 in)
1054 mm
(41.5 in)
533 mm
(21.0 in)
749 mm
(29.5 in)
