Nobles Marksman 412 - Page 29

PARTS LIST
LISTA DE PIEZAS
Marksmant 412 (01–01)
29
SOLUTION TANK GROUP
GRUPO DEL TANQUE DE SOLUCION
REF PART # DESCRIPTION QTY.
1 608427 SOL TANK, GREEN 1
2 608188 DECAL, ”NOBLES” 1
3 607298 DSTRAINER, SCREEN 1
4 609063 FOAM, SOUND 1
5 608453 DECAL, ”MARKSMAN 412” SIDE 2
6 230739 AXLE, 1/2DIAX13–1/8 1
7 140045 WASHER, 1/2 FLAT 2
8 607277 DWHEEL, 8”DIA GRAY 2
9 103019 CAP, HUB 2
10 607181 FOAM, SOUND 1
11 600385 SCREW, M6X1.0X20 4
12 140052 WASHER, 1/4 EXT 12
13 230746 BRACKET, AXLE OFFSET 2
14 609111 PLATE, SHIM 2
15 607179 DVAC, MOTOR 5.7 2S 120V 1
190155 DBRUSH, CARBON 2/PK for 607179 2
607281 DVAC, MOTOR 5.7 2S 230V 1
190159 DBRUSH, CARBON 2/PK for 607281 2
16 607276 HOSE, VAC 1–1/2IDX19” 1
17 140307 DCLAMP, HOSE 1
18 100143 DGASKET, VAC MOTOR 1
19 140340 SCREW, #10X5/8 4
20 14865 BUSHING 1
21 140297 NUT, M5X.8 HEX 1
22 608322 SCREW, M6X1.0X16 4
23 610997 PLATE, VAC MOTOR MTG 1
∇ ASSEMBLY
Y INCLUDED IN ASSEMBLY
D RECOMMENDED STOCK ITEMS
∇ CONJUNTO
Y INCLUIDO EN EL CONJUNTO
D ARTICULOS RECOMENDADOS PARA MANTENER EN EXISTENCIA
REF PART # DESCRIPTION QTY.
24 609064 FOAM, SOUND 1
∇25 607170 DTOOL, PICK–UP 13” ASSEMBLY 1
Y26 608324 SCREW, M6X1.0X40 4
Y27 607183 SEAL, CAP 1
Y28 140011 WASHER, 3/16 FLAT 1
Y29 140801 SCREW, 8–32X3/8 1
30 578859 DECAL, GROUND 1
31 140897 SCREW, GROUND 1
32 140032 WASHER, #6 FLAT 2
33 140826 SCREW #6X3/4 2
34 611305 CORD, 18/2X66” BLACK 1
35 140324 CLAMP, CABLE 5/16ID 1
36 140340 SCREW, #10X5/8 1
37 140011 WASHER, 3/16 FLAT 1
38 607275 HOSE, VAC 1–1/2IDX33” 1
39 140027 WASHER, 5/16 FLAT 4
40 611040 CORD, 18/5X41” 1
41 605395 BUSHING 1
42 611041 CORD, 18/5 X 54” 1
43 130698 BUSHING, SNAP 1
44 609112 FITTING, 1/4MX3/8H 1
45 608334 DHOSE, SIGHT–GAGE/DRAIN 1
46 150415 FITTING, 1/4MX3/8H 1
47 140301 DCLAMP, HOSE 1
