Nokia 7210 SAS-M User Manual

System Management
518
7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
3HE 16132 AAAB TQZZA Edition: 01
Context configure>system>resource-profile>egress-internal-tcam
Supported
Platforms
Supported on all 7210 SAS platforms as described in this document, including platforms
configured in the access-uplink operating mode
Description This command enables the user to allocate maximum resources for use by egress filter
policies using any of the supported match criteria. This command limits the total amount of
chunks allocated for use by egress filter policies to the value specified by num-resources. In
other words, the cumulative sum of chunks allocated to different match criteria supported by
filter policies cannot exceed the value configured with num-resources.
The no form of this command specifies that the software does not allocate any resources for
use by egress filter policies. If no resources are allocated for use, the software fails all
attempts to associate a service entity (for example, SAP and IP interface) with a filter policy
using any of the match criteria.
Parameters num-resources — Specifies the amount of resources that can be allocated for use by
ACL policies.
Values Table 44 lists the parameter values.
Note:
• The resources in the egress-internal-tcam resource pool are shared with other features
(for example, SAP egress aggregate meter). To assign resources to this feature,
resources may be reallocated from other features by disabling the policies association
with a SAP, and others.
• On the 7210 SAS platforms, some of the Egress ACL match criteria require a minimum
amount of resources greater than 1, to be allocated before the match criteria can be
used. In other words, use of SAP egress aggregate meter is mutually exclusive to use
of egress ACLs with the following match criteria - mac-ipv4 match, ipv6-128bit match,
mac-ipv6-64bit match. All these match criteria require a minimum of 2 resources. SAP
egress aggregate meter and egress ACLs MAC match criteria can be enabled
simultaneously, with each feature sharing the available resources equally among
them.
Table 44 Number of Resources Available for ACL-SAP-Egress
Platforms Min value
(per node)
Max value
(per node)
Default Values
7210 SAS-M (per node) 0 2 2
7210 SAS-T Network mode (per node) 0 2 2
7210 SAS-R6 (per IMMv1) 0 2 2
7210 SAS-R6 and 7210 SAS-R12(per
IMMv2)
022
