Nokia 7210 SAS-M User Manual

7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
System Management
Edition: 01 3HE 16132 AAAB TQZZA 521
mac-ipv4-match-enable
Syntax [no] mac-ipv4-match-enable num-resources
Context configure>system>resource-profile>egress-internal-tcam>acl-sap-egress
Supported
Platforms
Supported on all 7210 SAS platforms as described in this document, including platforms
configured in the access-uplink operating mode
Description This command allocates maximum resources for use by egress filter policies using IPv4
criteria or MAC criteria. The resources allocated are allocated on a first-come-first-serve
basis among service entities (for example, SAP and IP interface) using IPv4 and MAC criteria
egress filter policies.
The resources cannot be shared with any other egress filter policies that specify other match
criteria. Refer to the 7210 SAS-M, T, R6, R12, Mxp, Sx, S Router Configuration Guide for
more information on resource allocation and fields available for use.
The no form of this command specifies that the software does not allocate any resources for
use by egress filter policies using MAC or IPv4 criteria. If no resources are allocated for use,
the software fails all attempts to associate a service entity (for example, SAP and IP interface)
with a filter policy using this match criteria.
Default mac-ipv4-match-enable 2 (to maintain backward compatibility with earlier releases)
7210 SAS-T access-uplink mode (per node) 0 2 0
7210 SAS-T network mode (per node) 0 2 0
7210 SAS-Sx 1/10GE (standalone) 0 2 0
7210 SAS-Sx 1/10GE (standalone-VC) 0 2 0
7210 SAS-S 1/10GE (standalone) 0 2 0
7210 SAS-S 1/10GE (standalone-VC) 0 2 0
7210 SAS-Sx 10/100GE 0 2 0
7210 SAS-Mxp 0 2 0
7210 SAS-R6 and 7210 SAS-R12 0 2 0
7210 SAS-R6 (per IMM) 0 0 2
Table 45 Number of Resources Available for IPv6-128Bit-Match-Enable
Platforms Min value
(per node)
Max value
(per node)
Default
Values
