Parameters num-resources — Specifies the maximum amount of resources for use by this filter
match criteria. A minimum value of 2 (indicating two chunks of resources) must be
allocated to use this match-criteria. If not, association of a policy with mac and ipv4
criteria to a SAP will fail. It is mutually exclusive to use of SAP egress aggregate
meter.
Values Table 46 lists the parameter values.
mac-ipv6-64bit-match-enable
Syntax [no] mac-ipv6-64bit-match-enable num-resources
Context configure>system>resource-profile>egress-internal-tcam>acl-sap-egress
Supported
Platforms
Supported on all 7210 SAS platforms as described in this document, including platforms
configured in the access-uplink operating mode
Description This command allocates maximum resources for use by egress filter policies using MAC
criteria or IPv6 criteria using only the upper 64-bits of the IPv6 addresses. The resources
allocated are allocated on a first-come-first-serve basis among service entities (for example,
SAP and IP interface) using IPv6 64-bit and MAC criteria egress filter policies.
Table 46 Number of Resources Available for MAC-IPv4-Match-Enable
Platforms Min value
(per node)
Max value
(per node)
Default
Values
7210 SAS-M (per node) 0 2 0
7210 SAS-T access-uplink mode (per node) 0 2 0
7210 SAS-T network mode (per node) 0 2 0
7210 SAS-S 1/10GE (per node) (standalone) 0 2 0
7210 SAS-Sx 1/10GE standalone-VC) 0 2 2
7210 SAS-S 1/10GE (per node) (standalone) 0 2 0
7210 SAS-S 1/10GE (standalone-VC) 0 2 2
7210 SAS-Sx 10/100GE (per node) 0 2 2
7210 SAS-R6 and 7210 SAS-R12 IMM-c (per
node)
022
7210 SAS-Mxp 0 2 0
7210 SAS-R6 IMMv1 and IMMv2 0 2 0
7210 SAS-R12 IMMv2 0 2 0
