System Management
538
7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
3HE 16132 AAAB TQZZA Edition: 01
Refer to the 7210 SAS-M, T, Mxp, Sx, S Quality of Service Guide and the 7210 SAS-R6, R12
Quality of Service Guide for more information on resource allocation.
The no form of this command specifies that the software does not allocate any resources for
use by SAP ingress QoS policies using both MAC and IPv4 criteria. If no resources are
allocated for use, then software fails all attempts to associate a service entity (for example,
SAP and IP interface) with an ingress filter policy or SAP ingress QoS policy using this match
criteria.
Parameters num-resources — Specifies the maximum amount of resources for use by this match
criteria.
If the user specifies max, the software allocates one chunk when the first SAP is
associated with an ingress filter policy using this match criteria. It continues to
allocate resources to SAPs associated with an ingress filter policy using this criteria,
as long as the total amount of resources allocated does not exceed the resources
allocated to ingress filter policies (configured with the config system resource-
profile ingress-internal-tcam qos-sap-ingress-resource command) and chunks
are available for use.
Values Table 52 lists the parameter values.
Table 52 Number of Resources Available for IPv4-MAC-Match-Enable
Platforms Min value
(per node)
Max value
(per node)
Default
Values
7210 SAS-M (per node) 0 10 max
7210 SAS-T access-uplink mode (per node) 0 7 max
7210 SAS-T network mode (per node) 0 6 max
7210 SAS-R6 (per IMMv1) 0 7 max
7210 SAS-R6 and 7210 SAS-R12 (per IMMv2) 0 12 max
7210 SAS-R6 and 7210 SAS-R12 (per IMM-c) 0 10 max
7210 SAS-Mxp (per node) 0 10 max
7210 SAS-Sx 1/10GE (per node) (standalone) 0 7 max
7210 SAS-Sx 1/10GE (standalone-VC) 0 6 max
7210 SAS-S 1/10GE (per node) (standalone) 0 7 max
7210 SAS-S 1/10GE (standalone-VC) 0 6 max
7210 SAS-Sx 10/100GE (per node) 0 3 max
