Nokia 7210 SAS-M User Manual

System Management
546
7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
3HE 16132 AAAB TQZZA Edition: 01
cpu-protection
Syntax cpu-protection [num-resources]
no cpu-protection
Context configure>system>resource-profile>ingress-internal-tcam
Supported
Platforms
7210 SAS-R6 and 7210 SAS-R12
Description This command allocates CAM entries and meters for CPU protection rules and policies by
removing entries from other features that share the ingress internal TCAM resource pool.
Default 0
Parameters num-resources — Specifies the number of resources. Specifying the def keyword
specifies the default number of resources.
Values 0 to 2, def
Default 0
eth-cfm
Syntax eth-cfm num-resources
no eth-cfm
Context configure>system>resource-profile>ingress-internal-tcam
Supported
Platforms
Supported on all 7210 SAS platforms as described in this document, including platforms
configured in the access-uplink operating mode
Description This command enables the context to allocate resources for CFM UP MEPs and CFM Down
MEPs.
The no form of this command specifies that the software does not allocate any resources for
use by CFM UP MEPs, and it will allocate the default amount of resources for CFM Down
MEPs.
Parameters num-resources — Specifies the maximum amount of resources for use by ETH-CFM.
Values Table 58 lists the parameter values.
7210 SAS-Sx 10/100GE (per node) 0 3 max
Table 57 Number of Resources Available for MAC-Match-Enable
Platforms Min value
(per node)
Max value (per
node)
Default
Values
