7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
System Management
Edition: 01 3HE 16132 AAAB TQZZA 545
The resources cannot be shared with policies that use either IPv4 or IPv6 match criteria.
Refer to the 7210 SAS-M, T, Mxp, Sx, S Quality of Service Guide for more information about
the resource allocation for SAP ingress QoS policy.
The no form of this command specifies that the software does not allocate any resources for
use by SAP ingress QoS policies using mac criteria. If no resources are allocated for use, the
software fails all attempts to associate a service entity (for example, SAP and IP interface)
with a SAP ingress QoS policy using this match criteria.
Parameters num-resources — Specifies the maximum amount of resources for use by this filter
match criteria.
If the user specifies max, the software allocates one chunk when the first SAP is
associated with an ingress filter policy using this match criteria. It continues to
allocate resources to SAPs associated with SAP ingress QoS policy using this
criteria, as long as the total amount of resources allocated does not exceed the
resources allocated to SAP ingress QoS policies (configured with the config system
resource-profile ingress-internal-tcam qos-sap-ingress-resource command)
and chunks are available for use.
Values Table 57 lists the parameter values.
Table 57 Number of Resources Available for MAC-Match-Enable
Platforms Min value
(per node)
Max value (per
node)
Default
Values
7210 SAS-M (per node) 0 10 max
7210 SAS-T Access-Uplink mode (per
node)
07 max
7210 SAS-T Network Mode (per node) 0 6 max
7210 SAS-R6 (per IMMv1) 0 7 max
7210 SAS-R6 and 7210 SAS-R12 (per
IMMv2)
012 max
7210 SAS-R6 and 7210 SAS-R12 (per
IMM-c)
010 max
7210 SAS-Mxp (per node) 0 10 max
7210 SAS-Sx 1/10GE (per node)
(standalone)
07 max
7210 SAS-Sx 1/10GE (standalone-VC) 0 6 max
7210 SAS-S 1/10GE (per node)
(standalone)
07 max
7210 SAS-S 1/10GE (standalone-VC) 0 6 max
