System Management
544
7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
3HE 16132 AAAB TQZZA Edition: 01
If the user specifies max, the software allocates one chunk when the first SAP is
associated with an ingress filter policy using this match criteria. It continues to
allocate resources to SAPs associated with an ingress filter policy using this criteria,
as long as the total amount of resources allocated does not exceed the resources
allocated to ingress filter policies (configured with the config system resource-
profile ingress-internal-tcam acl-sap-ingress command) and chunks are
available for use.
Values Table 56 lists the parameter values.
mac-match-enable
Syntax mac-match-enable num-resources
no mac-match-enable
Context configure>system>resource-profile>ingress-internal-tcam>qos-sap-ingress-resource
Supported
Platforms
Supported on all 7210 SAS platforms as described in this document, including platforms
configured in the access-uplink operating mode
Description This command allocates maximum resources for use by SAP ingress QoS policies using
MAC criteria (any).
Table 56 Number of Resources Available for MAC-Match-Enable
Platforms Min value
(per node)
Max value
(per node)
Default
Values
7210 SAS-M (per node) 0 5 max
7210 SAS-T Access-Uplink mode (per node) 0 2 max
7210 SAS-T Network Mode (per node) 0 2 max
7210 SAS-R6 and 7210 SAS-R12 (per IMM) 0 10 max
7210 SAS-R6 and 7210 SAS-R12 IMM-c (per
IMM)
0 9 max
7210 SAS-Mxp (per node) 0 10 max
7210 SAS-Sx 1/10GE (per node)
(standalone)
06max
7210 SAS-Sx 1/10GE (standalone-VC) 0 5 max
7210 SAS-S 1/10GE (per node) (standalone) 0 6 max
7210 SAS-S 1/10GE (standalone-VC) 0 5 max
7210 SAS-Sx 10/100GE (per node) 0 4 max
