7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
System Management
Edition: 01 3HE 16132 AAAB TQZZA 543
mac-match-enable
Syntax mac-match-enable num-resources
no mac-match-enable
Context configure>system>resource-profile>ingress-internal-tcam>acl-sap-ingress
Supported
Platforms
Supported on all 7210 SAS platforms as described in this document
Description This command allocates maximum resources for use by ingress filter policies using mac
criteria.
The resources cannot be shared with policies that use either IPv4 or IPv6 match criteria.
Refer the 7210 SAS-M, T, R6, R12, Mxp, Sx, S Router Configuration Guide for more
information about the resource allocation for ingress filter policy and fields available for use
with ingress filter policy.
The no form of this command specifies that the software does not allocate any resources for
use by ingress filter policies using mac criteria. If no resources are allocated for use, the
software fails all attempts to associate a service entity (for example, SAP and IP interface)
with an ingress filter policy using this match criteria.
Parameters num-resources — Specifies the maximum amount of resources for use by this filter
match criteria.
7210 SAS-S 1/10GE (per node) (standalone) 0 6 0
7210 SAS-S 1/10GE (standalone-VC) 0 5 max
7210 SAS-Sx 10/100GE (per node) 0 4 0
Table 55 Number of Resources Available for IPv6-64-Only-Match-Enable
Platforms Min value
(per node)
Max value
(per node)
Default
Values
Note: Ingress ACL resources are shared with SAP ingress aggregate meter. See the sap-
aggregate-meter command for more information.
