Nokia 7210 SAS-M User Manual

System Management
542
7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
3HE 16132 AAAB TQZZA Edition: 01
Supported
Platforms
Supported on all 7210 SAS platforms as described in this document, including platforms
configured in the access-uplink operating mode
Description This command allocates maximum resources for use by ingress filter policies using ipv6
criteria with 64-bit IPv6 addresses. Refer to the 7210 SAS-M, T, R6, R12, Mxp, Sx, S Router
Configuration Guide for more information on resource allocation and fields available for use.
The resources cannot be shared with IPv4 filter policies or IPv6 filter policies specifying 128-
bit addresses.
Ingress ACL resources are shared with SAP ingress aggregate meter. See the sap-
aggregate-meter command for more information.
The no form of this command specifies that the software does not allocate any resources for
use by filter policies using ipv6 criteria with 64-bit IPv6 addresses. If no resources are
allocated for use, the software fails all attempts to associate a service entity (for example,
SAP and IP interface) with an ingress filter policy using this match criteria.
Parameters num-resources — Specifies the maximum amount of resources for use by this filter
match criteria.
If the user specifies max, the software allocates one chunk when the first SAP is
associated with an ingress filter policy using this match criteria. It continues to
allocate resources to SAPs associated with an ingress filter policy using this criteria,
as long as the total amount of resources allocated does not exceed the resources
allocated to ingress filter policies (configured with the config system resource-
profile ingress-internal-tcam acl-sap-ingress command) and chunks are
available for use.
Values Table 55 lists the parameter values.
Table 55 Number of Resources Available for IPv6-64-Only-Match-Enable
Platforms Min value
(per node)
Max value
(per node)
Default
Values
7210 SAS-M (per node) 0 5 max
7210 SAS-T Access-uplink mode (per node) 0 7 max
7210 SAS-T Network Mode (per node) 0 6 max
7210 SAS-R6 and 7210 SAS-R12 (per IMM) 0 5 max
7210 SAS-R6 and 7210 SAS-R12 IMM-c (per
IMM)
0 9 max
7210 SAS-Mxp (per node) 0 10 max
7210 SAS-Sx 1/10GE (per node)
(standalone)
060
7210 SAS-Sx 1/10GE (standalone-VC) 0 5 max
