Nokia 7210 SAS-M User Manual

7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
System Management
Edition: 01 3HE 16132 AAAB TQZZA 551
ip-mpls-protocols
Syntax ip-mpls-protocols num-resources
no ip-mpls-protocols
Context config>system>resource-profile>ing-internal-tcam
Supported
Platforms
7210 SAS-Mxp
Description This command configures an additional slice from the ingress-internal-tcam resource pool for
use by the IP and MPLS protocols.
On boot up, by default, the software allocates a single slice of entries from the ingress-
internal-tcam resource pool for use by the IP and MPLS control protocols. Entries from that
slice are allocated to the following protocols on a first-come-first-serve basis when the user
enables the protocol: OSPFv2, OSPFv3, BGP, IS-IS, LDP, RSVP, VRRP, MC-LAG,
VRRPv3, PCEP, PIM, IGMP, DHCP, DHCPv6, and PTP.
However, the default single slice of entries is not sufficient if all IP and MPLS control-plane
protocols are enabled simultaneously. To allocate an additional slice to IP and MPLS
protocols, use this command to set the value of num-resources to 2.
7210 SAS-R6 and 7210 SAS-R12 (per
IMMv2)
012max
7210 SAS-R6 and 7210 SAS-R12 (per IMM-
c)
010max
7210 SAS-Mxp (per node) 0 10 0
7210 SAS-Sx 1/10GE (per node)
(standalone)
070
7210 SAS-Sx 1/10GE (standalone-VC) 0 6 0
7210 SAS-S 1/10GE (per node) (standalone) 0 7 0
7210 SAS-S 1/10GE (standalone-VC) 0 6 0
7210 SAS-Sx 10/100GE (per node) 0 3 0
Table 59 Number of Resources Available for IPv6-IPv4-Match-Enable
Platforms Min value
(per node)
Max value
(per node)
Default
Values
