System Management
592
7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
3HE 16132 AAAB TQZZA Edition: 01
Context show>system
Supported
Platforms
Supported on all 7210 SAS platforms as described in this document, including platforms
configured in the access-uplink operating mode
Description This command displays system memory status.
Output The following output is an example of memory pool information, and Table 70 describes the
output fields.
Sample Output
A:ALA-1# show system memory-pools
===============================================================================
Memory Pools
===============================================================================
Name Max Allowed Current Size Max So Far In Use
-------------------------------------------------------------------------------
System No limit 24,117,248 24,117,248 16,974,832
Icc 8,388,608 1,048,576 1,048,576 85,200
RTM/Policies No limit 5,242,912 5,242,912 3,944,104
OSPF No limit 3,145,728 3,145,728 2,617,384
MPLS/RSVP No limit 9,769,480 9,769,480 8,173,760
LDP No limit 0 0 0
IS-IS No limit 0 0 0
RIP No limit 0 0 0
VRRP No limit 1,048,576 1,048,576 96
Services No limit 2,097,152 2,097,152 1,589,824
IOM No limit 205,226,800 205,226,800 202,962,744
SIM No limit 1,048,576 1,048,576 392
IGMP No limit 0 0 0
MMPI No limit 0 0 0
MFIB No limit 0 0 0
PIP No limit 79,943,024 79,943,024 78,895,248
MBUF 67,108,864 5,837,328 5,837,328 4,834,280
-------------------------------------------------------------------------------
Current Total Size : 343,495,200 bytes
Total In Use : 324,492,768 bytes
Available Memory : 640,178,652 bytes
===============================================================================
A:ALA-1#
Table 70 Output Fields: Memory Pool
Label Description
Name The name of the system or process
Max Allowed Integer — The maximum allocated memory size
No — Limit No size limit
Current Size The current size of the memory pool
Max So Far The largest amount of memory pool used
