Nokia WiFi Gateway 3 Product Guide Configure a Gateway 3 (G-240W-E)
Issue: 01 3FE-47464-AAAA-TCZZA 103
Procedure 31 Port forwarding configuration
1 Select Application > Port forwarding from the top-level menu in the Ethernet Gateway
window, as shown in Figure 39.
Figure 39 Port forwarding window
Table 37 describes the fields in the port forwarding window.
Table 37 Port forwarding parameters
Field Description
Application Name Choose an application name from the drop-down menu
WAN Port WAN port range
LAN Port LAN port range
Internal Client Choose a connected device from the drop-down menu and enter the associated
IP address
Protocol Choose the port forwarding protocol from the drop-down menu:
• TCP
• UDP
• TCP/UDP
Enable Mapping Select this check box to enable mapping
WAN Connection List Choose a WAN connection from the drop-down menu
Note: only active devices are shown on this menu
