Nokia WiFi Gateway 3 Product Guide Configure a Gateway 3 (G-240W-E)
Issue: 01 3FE-47464-AAAA-TCZZA 91
2 Choose a QoS type from the drop-down menu: L2 or L3.
3 Configure a QoS policy.
4 Click Add to add a QoS policy.
5 STOP. This procedure is complete.
8.1.4 Security configuration
The Gateway 3 (G-240W-E) also supports security configuration, including:
• Firewall
• MAC Filter
• IP Filter
• URL Filter
• Parental Control
• DMZ and ALG
• Access Control
Interface Choose an interface from the drop-down menu
DSCP Remark Enter the value for the DSCP mark (range: 0-63); valid only for L3 Criteria
802.1p Mark Enter the value for the 802.1p (range: 0-7)
Forwarding Policy Enter the number for the forwarding policy (range: 1-7)
Additional fields for L3
Protocol Choose a protocol from the drop-down menu, or select the Exclude check box
Application Choose an application from the drop-down menu
Source IP and
Source IP Mask
Enter the values for the source IP and IP mask, or select the Exclude check box
Destination IP and
Destination IP Mask
Enter the values for the destination IP and IP mask, or select the Exclude check box
Source Port and
Source Port Max
Enter the values for the source port and port max (highest port number) or select the
Exclude check box
Destination Port and
Destination Port Max
Enter the values for the destination port and port max (highest port number), or select
the Exclude check box
Field Description
(2 of 2)
