Nokia Gateway 3 User Manual

Configure a Gateway 3 (G-240W-E)
100
Nokia WiFi Gateway 3 Product Guide
3FE-47464-AAAA-TCZZA Issue: 01
Procedure 29 DMZ and ALG configuration
1 Select Security > DMZ and ALG from the top-level menu in the Ethernet Gateway window,
as shown in Figure 37.
Figure 37 DMZ and ALG window
Table 35 describes the fields in the DMZ and ALG window.
Table 35 DMZ and ALG parameters
2 Configure ALG.
3 Click Save ALG.
4 Configure DMZ.
Field Description
ALG Config Select the check boxes to enable the protocols to be supported by the ALG: FTP,
TFTP, SIP, H323, RTSP, L2TP, IPSEC, PPTP
DMZ Config
WAN Connection List Choose a WAN connection from the drop-down menu
Enable DMZ Select this check box to enable DMZ on the chosen WAN connection
DMZ IP Address Choose Customer Setting and enter the DMZ IP address or choose the IP address
of a connected device from the drop-down menu

Nokia Gateway 3 Specifications

General

Model	Nokia Gateway 3
Category	Wireless Router
Wireless Technology	Wi-Fi
Wi-Fi Standards	802.11ac
Frequency Bands	2.4 GHz, 5 GHz
USB Ports	1
Security Features	WPA
