Gateway 3 (G-240W-E) unit data sheet
42
Nokia WiFi Gateway 3 Product Guide
3FE-47464-AAAA-TCZZA Issue: 01
5.5 Gateway 3 (G-240W-E) LEDs
The circular top of the Gateway 3 (G-240W-E) functions as a multi-color LED
indicator. The LED color and pulse rate acts as a signal to the home user, which
indicates the state of the Gateway 3 and the quality of its backhaul link.
Table 9 provides LED descriptions for the Gateway 3 (G-240W-E).
Table 9 Gateway 3 (G-240W-E) LED indications
5.6 Gateway 3 (G-240W-E) detailed specifications
Table 10 lists the physical specifications for the Gateway 3 (G-240W-E).
Table 10 Gateway 3 (G-240W-E) physical specifications
Table 11 lists the power consumption specifications for the Gateway 3 (G-240W-E).
LED color LED behavior Router mode Bridge mode LED behavior description
Off Off ✓✓ Power off.
Blue-Green Solid ✓ Good backhaul connection to the Internet.
Solid ✓ Good backhaul connection. A link to the next node is
available.
Yellow Solid ✓ Backhaul connection is successful but not optimal. A
link to the next node is below standard.
Slow pulsing ✓✓ Configuration mode. The unit is waiting to be
configured.
Red Solid ✓ No connection to the Internet.
Solid ✓ Backhaul connection is not successful. A link to the
next node is not operational.
Fast pulsing ✓✓ Factory reset
White Slow pulsing ✓✓ WPS enabled
3 quick pulses ✓✓ WPS successful
Solid ✓✓ Powering on
Description Specification
Diameter 94 mm (3.7 in.)
Height 200 mm (78.7 in.)
Weight [within ± 0.5 lb (0.23 kg)] 857g (1.89 lb)
