Menu Description
Corner Adj.
Adjusts the shape and size of an image that is unevenly rectangular on
all sides. See “Adjusting 4 corners” on page 39 for details.
Warping
The function is to congure the geometric distortion of the projector’s
images when the images are projected onto screens which have a kind
of uneven surface such as a cylinder, a spherical shape, etc.
• Enable
Keystone and Corner Adj. will not be available when Warping is enabled.
• Warping Adj.
This function is available when On is selected in the Warping > Enable
menu.
1. Press OK to bring up the next menu. Then select whether to show
the grid pattern with the projected image or not.
2. Use Up / Down / Left / Right to move the cursor to the point
you wish to adjust.
3. Press OK to enter adjustment mode.
4. Use Up / Down / Left / Right to shift the point by x and y
coordinates.
5. When done, press OK to save the adjustment.
6. Repeat steps 4 and 5 to adjust another point until you are satised
with the projected image.
7. Press OSD Menu to exit and save the adjustment mode.
• Reset
Returns all settings made in the menu to the factory preset values.
Zoom Magnies the projected image and allows you to navigate the image.
OverScan Adjusts the overscan rate from 0 to 5.
