Adjusting the Projected Image
Fine-Tuning the Image Quality
To adjust the image to the size you need, press OSD Menu to open the OSD menu and go to the DISPLAY >
Motorized Zoom menu. Press Left / Right to reduce or magnify the image.
To improve the image clarity, just press Focus on the remote control. If you need to manually ne-tune the image clarity,
press Focus on the remote control for three (3) seconds to display the test pattern, then press Left / Right to adjust the
clarity.
Correcting Keystone
Keystoning refers to the situation where the projected image becomes a trapezoid due to angled projection. Refer to the
following instructions to correct the problem.
• Adjust the projection angle or height.
• If the installation location is not allowed to do so, you can perform the Auto Keystone function from the OSD menu.
1. Press OSD Menu to open the OSD menu.
2. Go to the DISPLAY > Keystone > Auto Keystone menu and select On.
• If you need to manually correct the image after the Auto Keystone adjustment, perform the following steps.
1. Press OSD Menu to open the OSD menu.
2. Go to the DISPLAY > Keystone > Manual menu and press OK .
3. Press Up / Down to highlight Vertical, Horizontal, or Rotation.
Highlight Vertical and press Left / Right to correct the vertical sides keystone.
Hightlight Horizontal and press Left / Right to correct horizontal sides keystone.
Highlight Rotation and press Left / Right to rotate the projected image clockwise or counterclockwise.
4. To reset the values, press OSD Menu to go back to the previous menu, highlight Auto Keystone and press Left / Right to
select On.
5. When done, press Return or OSD Menu to exit.
