Norac UC4 - Viewing the Actual Boom Height

5
36 34 36
36 AA 36
than two seconds reverts ALL booms (left, right, main and roll) to
MANUAL mode.
- this is a convenient method for switching to MANUAL mode
when folding for transport
3.3 ADJUSTING THE TARGET HEIGHT (SETPOINT)
The system is in AUTO and can have the
target height adjusted
 Use the " +/- " switch in AUTO mode to adjust the target height
setting.
 Alternately, adjust the main boom target height by momentarily
pressing the sprayer’s main lift control switch while in AUTO mode
- each press of the up/down switch increases/decreases the target
height by one inch, respectively
 The smallest target height setting is called the minimum height
override.
 Default minimum height settings are factory programmed before
shipping.
3.4 VIEWING THE ACTUAL BOOM HEIGHT
Left boom is at 36”, right center section is
at 34” and right boom is at 36”
 Toggle the "SENSOR DISPLAY" switch to view actual boom heights.
- the left, main (center) and right boom heights are displayed on this
screen
 To view additional sensor heights (if installed) toggle the "SENSOR
DISPLAY" switch again.
 To lock the currently viewed sensor heights on the screen indefinitely
toggle the " + " switch once
 Height menus can be viewed in both AUTO and MANUAL mode.
 More information on sensor height menus is available in the UC4
Technical Manual.
