Lubrication and Maintenance - Grader Components
Display
Symbol Meaning Remarks
ST AEB - Starter button is pressed
K1...K4, KV, KR
Calibrating clutch
K1...K4,KV,KR
_ and Kx
Wait for start, initialization of
clutch Kx
= and Kx
Fast fill time determination of
clutch Kx
= and Kx
Compensating pressure
determination of clutch Kx
OK
Calibration for all clutches
finished
Transmission stays in neutral, you
have to restart the TCU (ignition off/on)
after removing AEB starter.
STOP
AEB canceled (activation
stopped)
Transmission stays in neutral, you
have to restart the TCU (ignition off/on)
STOP and Kx
AEB stopped, clutch Kx can’t be
calibrated
Transmission stays in neutral, you
have to restart the TCU (ignition off/on)
Spanner and Kx
Kx couldn’t be calibrated, AEB
finished
Transmission stays in neutral, you
have to restart the TCU (ignition off/on)
Engine speed too low, -> raise
engine speed
Engine speed too high, -> lower
engine speed
Transmission oil temperature
too low, -> heat up transmission
Transmission oil temperature
too high, -> cool down
transmission
FT
Transmission temperature not in
defined range during calibration
Transmission stays in neutral, you
have to restart the TCU (ignition off/on)
FB
Operating mode not NORMAL
or transmission temperature
sensor defective or storing of
calibrated values to EEPROM -
has failed
Transmission stays in neutral, you
have to restart the TCU (ignition off/on)
FO Output speed_not_zero
Transmission stays in neutral, you
have to restart the TCU (ignition off/on)
FN Shift lever not in neutral position
Transmission stays in neutral, you
have to restart the TCU (ignition off/on)
FP Parkbrake_not_applied
Transmission stays in neutral, you
have to restart the TCU (ignition off/on)
STOP
AEB - Starter was used
incorrect or is defective
Transmission stays in neutral, you
have to restart the TCU (ignition off/on)
