NORAM 65ET GRADER
6-5
Lubrication and Maintenance - CAT Tier 4 Final
6
Every 10 Hours or Daily
Engine Air Precleaner - Check / Clean
1. Remove cover (1).
2. Check for an accumulation of dirt and debris in
body
(2).
3. Clean body.
4. Install cover and wing nut.
NOTE: When the engine is operated in dusty
applications, more frequent cleaning is required.
Engine Oil Level - Check
1. Park machine on a level surface. Allow engine oil to
settle for 5 minutes after the engine has stopped
before checking level.
2. Remove dipstick
(1) and check level. Oil level should
be above minimum mark and below maximum mark.
3. Remove fill cap
(2) and add or remove oil to obtain
proper fill level between minimum and maximum
marks.
4. Install the fill cap
(2).
NOTE: DO NOT overfill crankcase. The oil level
must not be above the FULL RANGE on the dipstick.
