NORAM 65ET GRADER
2-29
General Information
2
Electronic Display
Main Operating Screen
1. Transmission Gear
2. Engine RPM
3. Fuel Level
NOTE: When fuel level is < 5% the right amber
indicator lamp is illuminated.
4. Menu - Press Control Key associated with icon to enter
Menu Screen.
5. Diesel Exhaust Fluid Level (DEF)
NOTE: When DEF level is < 20% the right amber
indicator lamp is illuminated.
6. Operator Selected System Functions - Four operator
selected system parameters can be monitored in the
four quadrant display.
The parameters shown are:
•Engine RPM,
• Engine Coolant Temperature,
• Engine Oil Pressure, and
• Engine Hours.
Refer to Section 4,
"When Required", page 4-41 for parameters that can be selected for monitoring.
