MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset
13
DVI（18Bit DVI cable is recommended）：
Signal Name
Pin
Signal Name
TDC2#
1
2
TDC2
GND
3
4
NC
NC
5
6
SC-DDC
SD-DDC
7
8
NC
TDC1#
9
10
TDC1
GND
11
12
NC
NC
13
14
VCC
GND
15
16
HP-DETECT
TDC0#
17
18
TDC0
GND
19
20
NC
NC
21
22
GND
TLC
23
24
TLC#
GND
25
26
GND
NC
27
28
NC
LVDS：
VDD_PANEL
1
2
VDD_PANEL
VDD_PANEL
3
4
NC
GND
5
6
GND
LVDSA_DATA0#
7
8
LVDSA_DATA0
LVDSA_DATA1#
9
10
LVDSA_DATA1
LVDSA_DATA2#
11
12
LVDSA_DATA2
GND
13
14
GND
LVDSA_CLK#
15
16
LVDSA_CLK
LVDSA_DATA3#
17
18
LVDSA_DATA3
LVDSB_DATA0#
19
20
LVDSB_DATA0
LVDSB_DATA1#
21
22
LVDSB_DATA1
LVDSB_DATA2#
23
24
LVDSB_DATA2
GND
25
26
GND
LVDSB_CLK#
27
28
LVDSB_CLK
LVDSB_DATA3#
29
30
LVDSB_DATA3
